Automatic Warehouse Material Handling Scissor Lifting Transfer Carriage Steel Parts Transport Carts

Ask Lasest Price
Brand Name :	Topleader
Model Number :	KPJ
Certification :	CE,ISO9000
Price :	$8000
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	600 sets/year
Delivery Time :	30-40 days after receive your prepayment

Add to Cart

Product Details
Company Profile

Automatic Warehouse Material Handling Scissor Lifting Transfer Carriage Steel Parts Transport Carts

Brief Introduction - Material Handling Scissor Lifting Transfer Carriage

The Automatic Warehouse Material Handling Scissor Lifting Transfer Carriage Steel Parts Transport Carts can be turned in the order of magnitude. Adding PLC, the program is better, the performance is stronger. The Automatic Warehouse Material Handling Scissor Lifting Transfer Carriage was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and/or products through manufacturing facilities. Track traverser construction is based on our world renowned Lifting Transfer Carriage and provides controlled movement of heavy and oversized loads such as dies, coils and work in progress. Our Automatic Warehouse Material Handling Scissor Lifting Transfer Carriage Steel Parts Transport Carts is available in a number of configurations specifically designed to suit the needs of our customers.

Advantages - Material Handling Scissor Lifting Transfer Carriage

The kind of scissor lifting transfer carriage is with high level automation

Excellent gear reducer and motor with high quality, assemblied together perfectly

Safe devices are installed in the material handling scissor lifting transfer carriage

Remote control can be equipped together to operate the scissor lifting transfer carriage well

Customization can be supported for the scissor lifting transfer carriage

The transfer cart is equipped with collision safety protection device and sound and light alarm system, fast response, and short braking distance with an electromagnetic brake. Tubeless polyurethane or rubber wheel can be choosed according to the bearing tonnage, no damage to floor coating.

Automatic Warehouse Material Handling Scissor Lifting Transfer Carriage Steel Parts Transport Carts

Customized Options - Material Handling Scissor Lifting Transfer Carriage

Flat decks or fixtures customized for specific loads.

Custom deck configurations including built-in scales and lift/tilt/rotate capabilities.

Track or trackless, non-guided steering. Alternative drive and steering systems including gear reducer axle drives and individually-controlled drive wheels.

Fixed or variable speeds with forward/reverse function.

Drives with acceleration/deceleration capabilities.

Variety of operator control systems including fixed user interface, pendant control on coil cord, and radio-controlled remote operation.

Safety features including horns, flashing lights, e-stops, bumpers and collision avoidance systems.

Automatic Warehouse Material Handling Scissor Lifting Transfer Carriage Steel Parts Transport Carts

Parameters - Material Handling Scissor Lifting Transfer Carriage

Model		KPJ-2T	KPJ-5T	KPJ-10T	KPJ-20T	KPJ-30T	KPJ-50T	KPJ-100T	KPJ-150T
Rated load (T)		2	5	10	20	30	50	100	150
Table size	length(L)	2000	3500	3600	4000	4500	5500	6500	10000
	Width(W)	1500	2000	2000	2200	2200	2500	2800	3000
	Height(H)	450	450	500	550	600	650	850	1200
Wheel Base (mm)		1200	2500	2600	2800	3200	4200	4900	7000
Rail Inner Gauge (mm)		1200	1435	1435	1435	1435	1435	2000	2000
Wheel Diameter(mm)		Φ270	Φ300	Φ300	Φ350	Φ400	Φ500	Φ600	Φ600
Wheel Quantity(Nos)		4	4	4	4	4	4	4	8
Ground Clearance (mm)		50	50	50	50	50	50	75	75
Running speed (m/min)		0-30	0-30	0-25	0-25	0-25	0-20	0-20	0-18
Motor Power (Kw)		0.8	1.5	1.5	2.5	4	5.5	11	15
Max Wheel Load (KN)		14.4	25.8	42.6	77.7	110.4	174	343.8	265.2
Reference Weight (t)		2.5	3.5	4	5.6	6.5	7.8	14.1	26.2
Recommended Rail Model		P15	P18	P18	P24	P38	P43	QU100	QU100

Packing & Delivery - Material Handling Scissor Lifting Transfer Carriage

The Material Handling Scissor Lifting Transfer Carriage will be packed by the tarp, the parts will be packed by polywood case.
