    Custom Heavy Duty Electric Power Mold Transport Flat Rail Cart In Die Shop

    Ask Lasest Price
    Brand Name : Topleader
    Model Number : KPX-Mold Trtansport Carts
    Certification : CE,ISO9000
    Price : $3000-$12000
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 600 sets/year
    Delivery Time : 30-40 days after receive your prepayment
    • Product Details
    • Company Profile

    Custom Heavy Duty Electric Power Mold Transport Flat Rail Cart In Die Shop

    Custom Heavy Duty Electric Power Mold Transport Flat Rail Cart In Die Shop


    Product Introduction --- Mold Transport Flat Rail Cart


    KPX series Custom Heavy Duty Electric Power Mold Transport Flat Rail Cart In Die Shop is powered by battery. The battery installed in the flat rail carts, and the battery driven the motor to make the mold transport cart working.

    Compare wtih KPJ, KPD series, it is of the greater flexibility in security and mobility.The running distance is not limited and without demand of rail isolation, so the construction is convenient and the cost is low.

    This type of mold transport flat carts can provide the following optional parts for the customer to further improve the efficiency of (1) maintenance-free battery (2) import Promise speed control, dual speed control (3) the import of industrial wireless remote control.

    Custom Heavy Duty Electric Power Mold Transport Flat Rail Cart In Die Shop


    Product Details --- Mold Transport Flat Rail Cart


    Custom Heavy Duty Electric Power Mold Transport Flat Rail Cart In Die Shop


    Parameter --- Mold Transport Flat Rail Cart


    Model

    KPX-2T

    KPX-10T

    KPX-20T

    KPX-30T

    KPX-50T

    KPX-63T

    KPX-150T

    Rated load (T)

    2

    10

    20

    30

    50

    63

    150

    Table size

    length(L)

    2000

    3600

    4000

    4500

    5500

    5600

    10000

    Width(W)

    1500

    2000

    2200

    2200

    2500

    2500

    3000

    Height(H)

    450

    500

    550

    600

    650

    700

    1200

    Wheel Base (mm)

    1200

    2600

    2800

    3200

    4200

    4300

    7000

    Rail Inner Gauge (mm)

    1200

    1435

    1435

    1435

    1435

    1435

    2000

    Wheel Diameter(mm)

    Φ270

    Φ300

    Φ350

    Φ400

    Φ500

    Φ600

    Φ600

    Wheel Quantity

    4

    4

    4

    4

    4

    4

    8

    Ground Clearance (mm)

    50

    50

    50

    50

    50

    75

    75

    Running speed (m/min)

    0-25

    0-25

    0-20

    0-20

    0-20

    0-20

    0-18

    Motor Power (Kw)

    1

    1.6

    2.2

    3.5

    5

    6.3

    15

    Battery Capacity(Ah)

    180

    160

    180

    250

    330

    400

    600

    Battery Voltage(V)

    24

    48

    48

    48

    48

    48

    72

    Running Time When Full Load

    4.32

    4.8

    4

    3.5

    3.3

    3

    2.9

    Running Distance for one Charge(Km)

    6.5

    7.2

    4.8

    4.2

    4

    3.6

    3.2

    Max Wheel Load (KN)

    14.4

    42.6

    77.7

    110.4

    174

    221.4

    265.2

    Reference Weight (t)

    2.8

    4.2

    5.9

    6.8

    8

    10.8

    26.8

    Recommended Rail Model

    P15

    P18

    P24

    P38

    P43

    P50

    QU100


    Customized Options --- Mold Transport Flat Rail Cart


    Flat decks or fixtures customized for specific loads.

    Custom deck configurations including built-in scales and lift/tilt/rotate capabilities.

    Track or trackless, non-guided steering. Alternative drive and steering systems including gear reducer axle drives and individually-controlled drive wheels.

    Fixed or variable speeds with forward/reverse function.

    Drives with acceleration/deceleration capabilities.

    Variety of operator control systems including fixed user interface, pendant control on coil cord, and radio-controlled remote operation.

    Safety features including horns, flashing lights, e-stops, bumpers and collision avoidance systems.

    Custom Heavy Duty Electric Power Mold Transport Flat Rail Cart In Die Shop


    Applications --- Mold Transport Flat Rail Cart


    The mold transport flat rail cart can be widely used in assembly line (ring production line, loop production line), metallurgy industry (steel ladle), warehouse transport, ship industry (maintenance, assemble, container transport), workpiece transport in workshop, lathe transport, steel factory (steel billet, steel plate, steel coil, steel pipe, section steel, steel structure), construction(bridge, simple building, concrete, concrete column), petroleum industry (oil pump, sucker rod and parts), energy (polycrystalline silicon, generator, windmill), chemical industry (electrolytic cell, retort etc), railway (rail maintenance, rail welding, train tractor).

    Custom Heavy Duty Electric Power Mold Transport Flat Rail Cart In Die Shop


    Customer Visit


    Custom Heavy Duty Electric Power Mold Transport Flat Rail Cart In Die Shop


    Our After-Sale Service


    • Our commitment: The load bearing safety factor of the trolley is no less than 120%.

    • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.

    • 16 hours engineering service and 24 hours internet service for our customers.

    • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.

    • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
