5-30 Ton Material Handling Transfer Trolley For Dies, Molds, Steel
Coils Transport In Workshop
Brief Introduction --- Material Handling Transfer Trolley
The material handling transfer trolley is an electric driven factory material transport trolley which is
running on the rails. It can be powered by battery, low voltage
rails, cable reels, towed cable, sliding line, etc.
It is designed for material handling from one bay to another in the
working site. As the electric transfer trolleys are equipped with
steel wheels and move on steel rails, and the very low friction
between steel and steel, the material handling transfer trolleys
are suited to very high loading capacities.
Customized Options --- Material Handling Transfer Trolley
Flat decks or fixtures customized for specific loads.
Custom deck configurations including built-in scales and
lift/tilt/rotate capabilities.
Track or trackless, non-guided steering. Alternative drive and
steering systems including gear reducer axle drives and
individually-controlled drive wheels.
Fixed or variable speeds with forward/reverse function.
Drives with acceleration/deceleration capabilities.
Variety of operator control systems including fixed user interface,
pendant control on coil cord, and radio-controlled remote
operation.
Safety features including horns, flashing lights, e-stops, bumpers
and collision avoidance systems.
Product Advantages --- Material Handling Transfer Trolley
The kind of transfer trolley is with high level automation;
Excellent gear reducer and motor with high quality, assemblied
together perfectly;
Safe devices are installed on the material handling transfer
trolley;
The turning can be realized for this kinds of electric transfer
trolley, as "s", arc-shaped", "curved rail"...;
Customization can be supported;
With large capacity and high quality;
It can be applied in various occasions as high temperature,
ponding, dust, scrap iron...;
The hydraulic lifting device can be equipped as per customers'
demand;
The V frame can be installed for rounded material as per your need;
safety, flexibility, stable start, big starting torque, small
capacity to the gear reducer
Low voltage, long lifetime;
The running distance is not limited.
Parameter List --- Material Handling Transfer Trolley
Rated load (T) | 5 | 10 | 20 | 30 | 50 | 100 | 150 |
Table size | length(L) | 3500 | 3600 | 4000 | 4500 | 5500 | 6500 | 10000 |
Width(W) | 2000 | 2000 | 2200 | 2200 | 2500 | 2800 | 3000 |
Height(H) | 450 | 500 | 550 | 600 | 650 | 850 | 1200 |
Wheel Base (mm) | 2500 | 2600 | 2800 | 3200 | 4200 | 4900 | 7000 |
Rail Inner Gauge (mm) | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | 2000 |
Wheel Diameter(mm) | Φ300 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 |
Wheel Quantity(Nos) | 4 | 4 | 4 | 4 | 4 | 4 | 8 |
Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 |
Running speed (m/min) | 0-30 | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-18 |
Motor Power (Kw) | 1.5 | 1.5 | 2.5 | 4 | 5.5 | 11 | 15 |
Max Wheel Load (KN) | 25.8 | 42.6 | 77.7 | 110.4 | 174 | 343.8 | 265.2 |
Reference Weight (t) | 3.5 | 4 | 5.6 | 6.5 | 7.8 | 14.1 | 26.2 |
Recommended Rail Model | P18 | P18 | P24 | P38 | P43 | QU100 | QU100 |
Application --- Material Handling Transfer Trolley
This series material handling transfer trolley can be widely
applied in many fields, such as automobile, steel factory, heavy
industry, light industry, machinery, petroleum, metallurgy, mining,
chemical industry, engineering, aerospace, coal, nuclear energy,
shipyard, water conservancy, etc.
