10-45 Ton Rail Guided Container Motorized Transfer Carts Trolley On
Wheels
Brief Introduction --- Container Motorized Transfer Carts
10-45 Ton Rail Guided Container Motorized Transfer Carts Trolley On
Wheels with limitation of cable, it can get power from railways in
any time. However, it is has strict requirement for the railways,
which have to be insulated. (its rails is insulated with the
ground, and its wheels are insulated with the ground.)
Working Principle--- Container Motorized Transfer Carts
The power source AC380v is transformed into AC36v two-phase and are
respectively connected to the two rails. Then the wheels conduct
the AC36v on rail into the electrical appliance box at the bottom
of the motorized transfer carts, and then the AC36v is transformed
into DC36v and then control the DC motor through the DC control
system to make the container motorized transfer carts start, stop,
go forward and backward.
Product Funcation --- Container Motorized Transfer Carts
1. Load-Bearing Transport
Load-bearing transport is the most basic and important function of
transfer cart
2. Turning
This series of motorized transfer carts have the function of
running on S-shaped, C-shaped, curved rails, etc.
3. Lift
The hydraulic lift system can be installed on the motorized
transfer cart to achieve lifting and other functions
4. Side Flip
The transfer carts can realize self-discharging by the hydraulic
device
5. Safety Devices
Safety devices can be installed on the transfer carts, for example,
proximity switches, dead man stop, alarm systems, buffers to
achieve the corresponding safety functions.
6. Others
Our company can research and develop the corresponding non-standard
transfer carts to achieve the required functions according to the
customers’ requirements.
Working Environment --- Container Motorized Transfer Carts
1. Environment temperature: -20°C-40°C
2. Environment Humidity: Relative Humidity ≤ 70%
3. Environment PH Degree: Working in a Neutral or Approaching
Neutral
4. Environment Electrical Sustainability: 25%
5. Air Cleanliness: Non-corrosive, non-flammable,non-explosive gas
Parameter List --- Container Motorized Transfer Carts
Model | KPD-2T | KPD-5T | KPD-10T | KPD-20T | KPD-30T | KPD-50T | KPD-100T | KPD-150T |
Rated load (T) | 2 | 5 | 10 | 20 | 30 | 50 | 100 | 150 |
Table size(mm) | length | 2000 | 3500 | 3600 | 4000 | 4500 | 5500 | 6500 | 10000 |
Width | 1500 | 2000 | 2000 | 2200 | 2200 | 2500 | 2800 | 3000 |
Height | 450 | 500 | 500 | 550 | 600 | 650 | 900 | 1200 |
Wheel Base (mm) | 1200 | 2500 | 2600 | 2800 | 3200 | 4200 | 4900 | 7000 |
Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | 2000 |
Wheel Diameter(mm) | Φ280 | Φ300 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 |
Wheel Quantity(Nos) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 |
Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 |
Motor Power (Kw) | 1 | 1.2 | 1.6 | 2.2 | 3.5 | 5 | 10 | 15 |
Max Wheel Load (KN) | 14.4 | 25.8 | 42.6 | 77.7 | 110.4 | 174 | 343.8 | 265.2 |
Reference Weight (t) | 2.8 | 3.6 | 4.2 | 5.9 | 6.8 | 8 | 14.5 | 26.8 |
Recommended Rail Model | P15 | P18 | P18 | P24 | P38 | P43 | QU100 | QU100 |
Application --- Container Motorized Transfer Carts
The motorized transfer carts are widely applied in assembly line
(ring production line, loop production line), metallurgy industry
(steel ladle), warehouse transport, ship industry (maintenance,
assemble, container transport), workpiece transport in workshop,
lathe transport, steel factory (steel billet, steel plate, steel
coil, steel pipe, section steel, steel structure), construction
(bridge, simple building, concrete, concrete column), petroleum
industry (oil pump, sucker rod and parts), energy (polycrystalline
silicon, generator, windmill), chemical industry (electrolytic
cell, retort etc), railway (rail maintenance, rail welding, train
tractor).
