Workshop Bay To Bay Material Transfer Automatic Self Propelled Cart On Rail

Brief Introduction --- Automatic Self Propelled Cart On Rail

The kinds of Workshop Bay To Bay Material Transfer Automatic Self Propelled Cart On Rail, which is powered by conductor rail. It makes the AC electricity power is transformed into AC 36v two-phase and are respectively connected to the two rails. Then the wheel conduct the AC 36v on rail into the electrical appliance box at the bottom of the self propelled cart on rail. And then the AC 36v is transformed into DC 36v to control the DC motor. Use this principle to make the self propelled cart on rail, stop, go forward and backward, adjust the speed and so on.

Product Features --- Automatic Self Propelled Cart On Rail

1. High quality reducer, gears adopt CNC grinding technology, high precision, good contact, high transmission efficiency, high bearing capacity and long service life.

2. High quality motor, with a correspondingly fast, large starting torque, from zero speed to rated speed with rated torque performance.

3. The wheel adopts angular bearing seat for easy installation and adjustment, in order to properly improve the machining accuracy of the relevant parts to improve the accuracy of the self propelled cart's installation and manufacturing, to place the wheel deviation, the contact between the rim and the track intensifies the rim wear and increases the frictional resistance and so on.

4. High degree of automation, to achieve unmanned automated production processes.

Parameter List--- Automatic Self Propelled Cart On Rail

Application --- Automatic Self Propelled Cart On Rail

This series automatic self propelled cart on rail can be widely applied in many fields, such as automobile, steel factory, heavy industry, light industry, machinery, petroleum, metallurgy, mining, chemical industry, engineering, aerospace, coal, nuclear energy, shipyard, water conservancy, etc.

Operated Tips --- Self Propelled Trailer On Rail

1. The track laying of conductor rail powered self propelled trailer should be strict, and the insulation treatment of the track should be carried out.
2. Voltmeter and power meter instructions on ground power cabinet should be normal. Generally, the voltage slightly higher than 36V is normal.
3. To maintain the balance of the center of gravity of the self propelled trailer, it should be placed separately from the middle to both sides. When unloading the goods, the two ends should be unloaded first, and then the middle should be unloaded.
4. The conductive surface of trailer needs to be cleaned and polished regularly, and the insulators such as oil, rust and dust should be cleaned up so as to ensure the normal conductivity of the conductive surface.

Xinxiang New Leader Machinery Manufacturing Co., Ltd is devoted to manufacture and sell lifting and material handling equipment with 15 years experience. NEWLD is a professional and international handling equipment company integrating R&D, design, production and sales. It has a modern management team, technical team and production technician team.

Our company is located in Xinxiang city, Henan province, covering an area of 33,300 square meters. It has a modern large-scale factory building, world-advanced production equipment and office equipment. The company has more than 150 employees, including 8 engineers and more than 20 technicians. The company has a first-class research and design team, which can undertake the design and production of various non-standard handling equipment.

NEWLD can not only provide transfer cart quotations, but also provide you with satisfactory handling solutions.

We can produce 1-1500 ton range of various tonnage of AGV, RGV, rail transfer cart, trackless transfer cart, flatbed trailer, towing tractor, locomotive turntable, industrial turntable and so on with more than 90 products. Customized all kinds of function required, such as turning, lifting, tilting, climbing, roller, anti-high temperature, anti-explosion, etc.. Newld also can provide transfer cart parts, including rail wheel, rail and rail accessories, industrial winch and so on.

Our products have a wide application field including metallurgy industry, machinery manufacturing industry, steel mill, mine industry, power industry, mold industry, automobile assembly industry, shipyard industry etc.

Our product has been exported to more than 90 countries and regions, such as Indonesia, America, Russia, Brazil, United Arab Emirates, Pakistan, Middle East, Saudi Arabia, Bangladesh, Philippines, Canada, Azerbaijani, Kuwait, Dubai, Egypt, Nepal, Vietnam, Laos, Myanmar, Germany, etc.
