Paper plant billet factory 15t material transfer V-block coil rail
cart
Introduction
The V/U frame fixed on the electric flat cart determines its
distance and quantity according to the size of the workpiece to be
carried and the number of single transportation. The user informs
us of the size of the workpiece, and our technicians can design a
program that is satisfactory to the user. The V/U-frame of the coil
cart can be selected: adjustable distance V-frame and fixed V-frame
welded to the table.
Heavy Duty Steel Coil Handling Electric Flat Car Battery Powered
With E Frame Heavy Duty Steel Coil Handling Electric Flat Car
Battery Powered With E Frame
Heavy Duty Steel Coil Handling Electric Flat Car Battery Powered
With E Frame Heavy Duty Steel Coil Handling Electric Flat Car
Battery Powered With E Frame
Product Details
Parameter List
Model | KPX-5T | KPX-10T | KPX-20T | KPX-30T | KPX-50T | KPX-100T | KPX-150T |
Rated load (T) | 5 | 10 | 20 | 30 | 50 | 100 | 150 |
Table size(mm) | length | 3500 | 3600 | 4000 | 4500 | 5500 | 6500 | 10000 |
Width | 2000 | 2000 | 2200 | 2200 | 2500 | 2800 | 3000 |
Height | 500 | 500 | 550 | 600 | 650 | 900 | 1200 |
Wheel Base (mm) | 2500 | 2600 | 2800 | 3200 | 4200 | 4900 | 7000 |
Rail Inner Gauge (mm) | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | 2000 |
Wheel Diameter(mm) | Φ300 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 |
Wheel Quantity(Nos) | 4 | 4 | 4 | 4 | 4 | 4 | 8 |
Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 |
Motor Power (Kw) | 1.2 | 1.6 | 2.2 | 3.5 | 5 | 10 | 15 |
Battery Capacity (Ah) | 180 | 160 | 180 | 250 | 330 | 440 | 600 |
Battery Voltage (V) | 36 | 48 | 48 | 48 | 48 | 72 | 72 |
Running speed (m/min) | 0-30 | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-18 |
Running Time When Full Load(Hours) | 5.4 | 4.8 | 4 | 3.5 | 3.3 | 3.2 | 3.2 |
Running Distance for One Charge(Km) | 8.1 | 7.2 | 4.8 | 4.2 | 4 | 3.8 | 3.2 |
Max Wheel Load (KN) | 25.8 | 42.6 | 77.7 | 110.4 | 174 | 343.8 | 265.2 |
Reference Weight (t) | 3.6 | 4.2 | 5.9 | 6.8 | 8 | 14.5 | 26.8 |
Recommended Rail Model | P18 | P18 | P24 | P38 | P43 | QU100 | QU100 |
Heavy Duty Steel Coil Handling Electric Flat Car Battery Powered
With E Frame Heavy Duty Steel Coil Handling Electric Flat Car
Battery Powered With E Frame
Application
Mounted reel can be widely used in assembly line (loop line,
circular line) (ladle), storage and transportation, metallurgical
industry, shipping industry (maintenance, assembly, container
transport), workpiece transportation, lathe workshop, molding
workshop (transport mold, mold from a bay to another), steel mills,
steel billet, steel plate, steel coil, steel pipe, steel, steel
structure), Construction (bridge, simple building, concrete,
concrete column), petroleum industry (oil pump, sucker rod and
parts), energy (polysilicon, generator, windmill), chemical
industry (electrolytic cell, distillation tank, etc.), etc
Company Information
Xinxiang New Leader Machinery Manufacturing Co., Ltd is devoted to
manufacturing material handling and lifting equipment with ISO9001,
CE, SGS and SASO certificates. Four series products, namely
transfer trolley, turntable, wheel and winch, can be designed and
manufactured according to your request. We are also a professional
supplier of GB standard steel rail and accessories. Our products
are exported to more than 50 countries
Our Service
1)We have a professional design and development team, providing the
best solution for you after knowing your actual demand;
2)We can provide the free training to end-users, we have a strong
production capacity, which can enable us to guarantee the delivery
time of battery powered rail transfer cart;
3)Low charge for continue maintenance of battery powered rail
transfer car when 12 month warranty is expired;
4)We can manufacture the large tonnage battery powered rail
transfer car with adjustable working speed;
5)Once cooperation, we can provide overseas lifelong technical
guidance or support freely for you.
