For sale processing custom electric remote rail cart transport

Xinxiang New Leader Machinery Manufacturing Co., Ltd
Contact Now
    Buy cheap For sale processing custom electric remote rail cart transport from wholesalers

    Buy cheap For sale processing custom electric remote rail cart transport from wholesalers
    • Buy cheap For sale processing custom electric remote rail cart transport from wholesalers
    • Buy cheap For sale processing custom electric remote rail cart transport from wholesalers
    • Buy cheap For sale processing custom electric remote rail cart transport from wholesalers
    • Buy cheap For sale processing custom electric remote rail cart transport from wholesalers

    For sale processing custom electric remote rail cart transport

    Ask Lasest Price
    Brand Name : Topleader
    Model Number : KPX
    Certification : CE,ISO9000
    Price : $3000-$12000
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 600 sets/year
    Delivery Time : 30-40 days after receive your prepayment
    • Product Details
    • Company Profile

    For sale processing custom electric remote rail cart transport

    For sale processing custom electric remote rail cart transport


    Introduction


    The railway flatbed car is powered by battery, and the electrical control system supplies power to the DC traction motor to realize the forward, backward and speed adjustment of the vehicle. It has the characteristics of simple structure, convenient use, large bearing capacity, convenient maintenance and long service life. Not limited by running distance, with customizable load capacity, can drive on curved track, and can adjust speed, wireless remote control is simple and convenient to operate, stable performance, improves operation efficiency, saves labor cost, can be customized according to customer needs Customized, can adapt to various operating environments, and the track laying requirements are not high, it is the first choice for factory handling.


    For sale processing custom electric remote rail cart transport


    Advantage


    The transfer cart, literally speak, it is a transfer cart with rails, which is the traditional and mature type transfer cart. More importantly, it has been new favorite in the industry transport field all over the world with hot market. Especially for the workshop transportation.


    1.The material transfer cart can run on the Vertical rails, ”L”rails, “S”rails, arc-shaped rails...

    2.The material transfer cart can be applied in many occasions, such as easy explosion, high temperature, ferry...

    3.DC motor, stable start, starting torque, small impact to gear reducer, low voltage, long lifetime...

    4.This kinds of material transfer cart is battery powered, so only charged fully, can it run freely without limited distance.

    5.Professional team from Xinxiang New Leader Machinery Manufacturing Co., Ltd. the proper solution can be provided once getting for your inquiry.

    6.The material transfer cartare customized as per your true demand.


    For sale processing custom electric remote rail cart transport


    Detail


    For sale processing custom electric remote rail cart transport


    Parameter List


    Rated load (T)

    2

    10

    20

    30

    50

    63

    150

    Table size

    length(L)

    2000

    3600

    4000

    4500

    5500

    5600

    10000

    Width(W)

    1500

    2000

    2200

    2200

    2500

    2500

    3000

    Height(H)

    450

    500

    550

    600

    650

    700

    1200

    Wheel Base (mm)

    1200

    2600

    2800

    3200

    4200

    4300

    7000

    Rail Inner Gauge (mm)

    1200

    1435

    1435

    1435

    1435

    1435

    2000

    Wheel Diameter(mm)

    Φ270

    Φ300

    Φ350

    Φ400

    Φ500

    Φ600

    Φ600

    Wheel Quantity

    4

    4

    4

    4

    4

    4

    8

    Ground Clearance (mm)

    50

    50

    50

    50

    50

    75

    75

    Running speed (min)

    0-25

    0-25

    0-20

    0-20

    0-20

    0-20

    0-18

    Max Wheel Load (KN)

    14.4

    42.6

    77.7

    110.4

    174

    221.4

    265.2

    Reference Weight (t)

    2.8

    4.2

    5.9

    6.8

    8

    10.8

    26.8

    Recommended Rail Model

    P15

    P18

    P24

    P38

    P43

    P50

    QU100


    Application


    Electric battery flat car can be widely used in a variety of working environment, production workshop, machinery manufacturing, automobile industry, warehouse transportation, mold industry, plastic industry, electronic factory, metallurgy industry, coal mining and so on


    For sale processing custom electric remote rail cart transport


    Delivery & Package


    For sale processing custom electric remote rail cart transport


    Customer Visit


    For sale processing custom electric remote rail cart transport


    About us

    For sale processing custom electric remote rail cart transport


    After-sales

    For sale processing custom electric remote rail cart transport


    Q&A


    Q: Whether you product can be customized?
    A: Sure. All our products are customized as per customers’ requirement, because different products are with different requirements of specification. The proper solution will be provided according to your true demand.
    Q: What is the size and load of this Rail Coil Transfer Car?
    A:The size and load of our this rail coil transfer car is customized design according to your requirement.
    Q: How do transfer cart been shipped?
    A: We export the transfer cart by sea or train with full container, LCL or in Bulk.

    Q: What is the leading time, delivery term, and payment term?

    A: Usually our leading time is 30 days.

    About the delivery term, we accept ,FOB, CIF. About the payment, we accept T/T or L/C, etc.
    Q: Can we choose the power supply for industry transport cart?
    A: Yes,such as the cable drum, battery powered ,low voltage powered, busbar powered ,trailing cable powered, etc.

    tags:steel plant steerable transfer vehicle,steel plant rail vehicle
