    40t Electric Trackless Transport Platform For Metal Parts Handling In Foundry Plant

    Ask Lasest Price
    Brand Name : Topleader
    Model Number : BWP-40T
    Certification : CE,ISO9000
    Price : $7000-$12000
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 600 sets/year
    Delivery Time : 30-40 days after your prepayment
    • Product Details
    • Company Profile

    40t Electric Trackless Transport Platform For Metal Parts Handling In Foundry Plant

    40t Electric Trackless Transport Platform For Metal Parts Handling In Foundry Plant


    Working Principle of Trackless Transport Platform


    The trackless transport platform is powered by storage battery. The battery is installed in the trackless transport platform cart and we also equip intelligent charger for it. The trackless transport platform is controlled to go forward, backward, turn left, turn right, adjust speed through PLC and speed controller.


    40t Electric Trackless Transport Platform For Metal Parts Handling In Foundry Plant


    Description of Trackless Transport Platform


    The trackless transport platform is composed of motor, reducer, electric appliance and wheels. Due to more parts, compared with other carts, it has large size. But it travels flexibly.
    The driving wheel and load wheel of trackless platform car is high strength PU wheel. It is wear-resistance, and has low maintain cost.
    The functions of the trackless transport platform including 360 degree turning, go forward and backward, turn left and right, adjust speed button, indicator light, electric indicator light and other control buttons.




    Advantage of Trackless Transport Platform


    The motor adopts DC traction motor, the protection grade: IP44. Compact structure, large overload capacity, long service life. Excellent load performance, good low-speed performance, big starting torque, small starting current. It is suitable for frequent start and saves electricity. The motor runs with high efficiency in the range of all speeds. The motor adopts imported high-speed bearing retaining oil, and it is of free maintenance, high reliability and long service life.

    40t Electric Trackless Transport Platform For Metal Parts Handling In Foundry Plant


    Application of Trackless Transport Platform


    This kind of trackless transport platform is commonly applied in factory or warehouse to transfer heavy materials, such as steel workpiecs, machine parts etc.


    40t Electric Trackless Transport Platform For Metal Parts Handling In Foundry Plant 40t Electric Trackless Transport Platform For Metal Parts Handling In Foundry Plant
    40t Electric Trackless Transport Platform For Metal Parts Handling In Foundry Plant 40t Electric Trackless Transport Platform For Metal Parts Handling In Foundry Plant


    Technical Parameters of Trackless Transport Platform


    Model

    BWP-40T

    Rated Load(t)

    40t

    Impacted rated load(t)

    45

    structure of frame

    steel plates welded beam structure

    Thickness of the steel plate

    14

    Cart weight(t)

    8.8

    Wheel load(t)

    7.7

    Ground requirement

    cement ground

    Table size(mm)

    5000x2200

    Height of the whole cart(mm)

    650

    Space from the ground(mm)

    50

    Wheels distance

    1700

    Axles distance

    4300

    Turning radius(mm)

    4300

    Turning type

    turning while driving without stop

    Control method for turning

    control button

    Turning structure

    mechanical

    Wheel diameter

    Ф400/4

    Wheel quality

    polyurethane wheels

    Running speed(m/min)

    0-12

    Brake principle

    electric magnetic force

    Operation method

    with wire or no wire

    Charger motor's installation

    installed on cart

    Function of charger motor

    automatic charging

    Warning equipment

    sound and light lamp


    Tags:Material Handling Transport Platform,Trackless Motorized Transfer Cart
