    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor

    Ask Lasest Price
    Brand Name : Topleader
    Model Number : KPX-40T
    Certification : CE,ISO9000
    Price : $7000-$12000
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 600 sets/year
    Delivery Time : 30-40 days after your prepayment
    • Product Details
    • Company Profile

    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor

    Aoto parts handling remote control steerable transport car on cement floor



    Working principle of steerable transport car


    This power of this kind of steerable transport car is storage battery, according to different working condition, lead-acid battery, free-maintenance battery and lithium battery can be chosen.


    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor


    Description of transport car on cement floor


    The whole steerable transport car is composed of motor, reducer, electric appliance and wheels. Due to more parts, compared with other carts, it has large size. But it travels flexibly.

    The driving wheel and load wheel of trackless car is high strength PU wheel. It is wear-resistance, and has low maintain cost.

    The functions of the transport car including 360 degree turning, go forward and backward,turn left and right, adjust speed button, indicator light, electric indicator light and other control buttons.







    Application of steerable transport car


    This kind of mold cart is commonly applied in factory or warehouse to transfer heavy materials, such as steel workpiecs, machine parts, etc.


    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor
    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor
    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor


    Technical parameters of transport car


    Model

    KPX-2T

    KPX-10T

    KPX-20T

    KPX-30T

    KPX-50T

    KPX-63T

    KPX-150T

    Rated load (T)

    2

    10

    20

    30

    50

    63

    150

    Table size

    length(L)

    2000

    3600

    4000

    4500

    5500

    5600

    10000

    Width(W)

    1500

    2000

    2200

    2200

    2500

    2500

    3000

    Height(H)

    450

    500

    550

    600

    650

    700

    1200

    Wheel Base (mm)

    1200

    2600

    2800

    3200

    4200

    4300

    7000

    Rail Inner Gauge (mm)

    1200

    1435

    1435

    1435

    1435

    1435

    2000

    Wheel Diameter(mm)

    Φ270

    Φ300

    Φ350

    Φ400

    Φ500

    Φ600

    Φ600

    Wheel Quantity

    4

    4

    4

    4

    4

    4

    8

    Ground Clearance (mm)

    50

    50

    50

    50

    50

    75

    75

    Running speed (min)

    0-25

    0-25

    0-20

    0-20

    0-20

    0-20

    0-18

    Motor Power (Kw)

    1

    1.6

    2.2

    3.5

    5

    6.3

    15

    Running Time When Full Load

    4.32

    4.8

    4

    3.5

    3.3

    3

    2.9

    Running Distance for one Charge(Km)

    6.5

    7.2

    4.8

    4.2

    4

    3.6

    3.2

    Max Wheel Load (KN)

    14.4

    42.6

    77.7

    110.4

    174

    221.4

    265.2

    Reference Weight (t)

    2.8

    4.2

    5.9

    6.8

    8

    10.8

    26.8

    Recommended Rail Model

    P15

    P18

    P24

    P38

    P43

    P50

    QU100


    Manufacturing of transport car on cement floor


    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor


    Delivery of transfer car


    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor


    Customer visit in our factory from world wide


    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor


    Rail transfer cart applied at site in customers' factory



    Aoto Parts Handling Remote Control Steerable Transport Car On Cement Floor


    After-sale service

    • Our commitment: The load bearing safety factor of the trolley is no less than 120%.

    • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.

    • 16 hours engineering service and 24 hours internet service for our customers.

    • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.

    • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
